Explore guide
Choose fabric count for a fixed design
Compare physical size and sampled coverage while keeping the chart’s stitch dimensions unchanged.
Related lessons and tools
Compare physical size and sampled coverage while keeping the chart’s stitch dimensions unchanged.
Before you start
Have the chart key, chart width and height, fabric thread count and threads crossed by each stitch. Keep floss strands separate from fabric threads.
How to do it
- How does fabric count change a stitched design’s size? — Compare one 140 × 98-stitch design at two fabric counts, without changing its chart.
- Understand stitching over one and two — Effective stitches per inch equal fabric threads per inch divided by threads crossed per stitch. Over-two work on 28-count fabric has 14 stitches per inch.
- Choose strands with a coverage sample — Compare coverage at the actual stitch length and fabric count. More strands add bulk as well as coverage and may enlarge holes.
- Add finishing margins without enlarging the stitched design — A 140 × 98-stitch design at 14 count over one measures 25.4 × 17.78 cm. A chosen 5 cm margin on every side needs 35.4 × 27.78 cm of fabric.
Try this example
A 140 × 98 design measures 25.4 × 17.78 cm on 14-count fabric and about 22.23 × 15.56 cm on 16-count fabric, both worked over one. Choose the size, then sample thread coverage before cutting finishing margins.
Check your result
- Count from two independent reference points before filling a large area. Verify the outer stitched dimensions on the actual ground; include finishing fabric separately.
- Changing fabric count changes physical size, not chart complexity. Fractional stitches, mixed scales and non-square grounds need explicit chart instructions.
Sources
Cross-stitch fabric planner
Turn chart stitches and fabric count into finished and cutting dimensions.
Before you use this tool
Count chart squares, not centimetres. Fabric threads crossed per stitch means over-one or over-two; it is separate from the number of floss strands.
The design size excludes finishing margins; the cut size includes your chosen margin on all four sides.
Method and limits
Formula and assumptions
Design size equals chart stitches divided by effective stitches per unit. Choose one fabric thread per stitch for over-one or two for over-two; the selected or custom margin is added on every side.
Worked example
Example: 140 × 98 stitches on fabric with 55 threads/10 cm produces a 25.5 × 17.8 cm design; a 5 cm margin needs a 35.5 × 27.8 cm fabric cut.
Limits and rounding
Results are planning estimates from the values entered. Displayed decimals are rounded for craft use; whole materials and repeats round up where the method says so. Confirm gauge, material behavior, construction, and finished measurements before committing supplies.
Cross-stitch fabric planner
Turn chart stitches and fabric count into finished and cutting dimensions.
Before you use this tool
Count chart squares, not centimetres. Fabric threads crossed per stitch means over-one or over-two; it is separate from the number of floss strands.
The design size excludes finishing margins; the cut size includes your chosen margin on all four sides.
Method and limits
Formula and assumptions
Design size equals chart stitches divided by effective stitches per unit. Choose one fabric thread per stitch for over-one or two for over-two; the selected or custom margin is added on every side.
Worked example
Example: 140 × 98 stitches on fabric with 55 threads/10 cm produces a 25.5 × 17.8 cm design; a 5 cm margin needs a 35.5 × 27.8 cm fabric cut.
Limits and rounding
Results are planning estimates from the values entered. Displayed decimals are rounded for craft use; whole materials and repeats round up where the method says so. Confirm gauge, material behavior, construction, and finished measurements before committing supplies.
